Our Products : Bar & Hollow Bar : AL-6XN/00Cr20Ni24Mo7N Bar & Hollow Bar
| Standard: | AISI, ASTM, UNS, SAE, JIS, B.S., DIN |
| Grades: | |
| Dimensions(mm): | 3-3000mm |
| Place of Origin: | Sichuan, China (Mainland) |
| Technique: | Hot-rolled |
| Payment Terms: | 30% advanced payment,the balance will be paid before shipment. |
| Minimum Order Quantity: | 1.5 Ton/Tons |
| Port: | Chongqing & Shanghai |
| Packaging Details: | in bundle according to your requirement |
| Delivery Time: | about 30-90 days |
| Supply Ability: | 500000 Ton/Tons per Month |
Detailed Product Description
AL-6XN/00Cr20Ni24Mo7N Bar & Hollow Bar
Physical Properties：
Density： 8.00g/cm3 Melting Point：1370-1398℃
Modulus of Elasticity： 290GPa Thermal Conductivity：90(BTU-in/ ft2-h-°F)
Hardness： Brinell280 Electrical Resistivity( 20 - 100°C)：8.5IN./ IN./ °F x 10-6
Main Characteristics：High strength; excellent chloride corrosion resistance and stress corrosion cracking resistance
Applications：Used in high chloride media: chemical with high sodium hypochlorite, chlorine dioxide, halogen, salt or seawater
Specification：Forgings,Rod, Plate, Strip,Ring, Wire, Bolts, Springs and other consultations supply, according to customer's production
Chemical Compositions：
| Chemical Compositions(%) | |||||||||||||
| C | Cr | Ni | Fe | Mn | Si | P | S | N | Mo | Cu | |||
| 0.02 max | 19.5 - 20.5 |
17.5 - 18.5 |
rem | 1.0 max | 0.80 max | 0.030 max | 1.0 max | 0.18 - 0.22 |
8.0 - 8.5 |
0.5 - 1.0 |
|||
